HVAC Thermostats

Find the right thermostat for your HVAC system — from basic non-programmable units to WiFi-enabled smart thermostats. We carry OEM replacements for Carrier, Honeywell, White-Rodgers, and Emerson, p...

419 parts in stock Same-day shipping 30-day returns

Find the exact thermostat for your unit

Select your brand and enter the model number from your equipment data plate.

1 Select your brand

2 Enter your model number

Shop by Specs

Browse the products below or use the model number lookup above.

Type

Stages

How to Choose the Right HVAC Thermostat

The thermostat is the user interface for your HVAC system, controlling when heating and cooling cycles start and stop based on your temperature settings. Choosing the right thermostat depends on your system type, wiring configuration, and desired features. All thermostats at National HVAC Parts are compatible with 24V low-voltage HVAC systems used in most residential and light commercial applications.

Non-Programmable vs Programmable

Non-programmable thermostats maintain a single set temperature until you manually change it. They are simple, reliable, and ideal for spaces with consistent occupancy. Programmable thermostats allow you to set different temperatures for different times of day and days of the week, automatically adjusting to save energy when you are away or sleeping. Most programmable models offer 7-day, 5-2, or 5-1-1 scheduling options.

System Compatibility: Stages and Heat Types

Thermostats are rated by the number of heating and cooling stages they support. A 1H/1C thermostat controls single-stage heating and cooling, which is the most common residential configuration. 2H/1C or 2H/2C thermostats support two-stage or dual-fuel systems (heat pump with gas backup). Always match the thermostat stages to your system to ensure all equipment operates correctly.

Heat Pump vs Conventional

Heat pump systems require a thermostat with a dedicated O/B terminal for the reversing valve. Conventional gas or electric furnace systems use standard heating terminals. Many modern thermostats support both system types with a selectable setting. If you have a heat pump, verify the thermostat explicitly lists heat pump compatibility before purchasing.

Wiring and Voltage

Most residential thermostats use 24V low-voltage wiring with standard thermostat wire (typically 18/5 or 18/8). Common terminal designations are R (power), W (heat), Y (cool), G (fan), C (common for power), and O/B (reversing valve). A C-wire provides continuous 24V power and is required for most smart and WiFi thermostats. If your home lacks a C-wire, look for thermostats with battery backup or C-wire adapter compatibility.

Finding Your Replacement

Check your existing thermostat wiring and system type before ordering. Use our Look Up by Model Number tool above to find the exact OEM thermostat for your unit, or browse our selection by type. Every order placed before 3 PM CST ships same day from National HVAC Parts.

Frequently Asked Questions

Do I need a C-wire for my thermostat?

Basic non-programmable and many programmable thermostats run on batteries and do not require a C-wire. Most WiFi and smart thermostats require a C-wire for continuous power. If your system does not have a C-wire run to the thermostat, you can use an add-a-wire adapter or choose a thermostat model designed to work without one.

Can I use a programmable thermostat with a heat pump?

Yes, but it must be rated for heat pump use with an O/B terminal for the reversing valve. Avoid using standard setback programming with heat pumps, as large temperature swings trigger expensive auxiliary heat strips. Look for thermostats with adaptive recovery or heat pump-specific algorithms that raise temperature gradually.

What is the difference between 1H/1C and 2H/2C?

1H/1C means the thermostat controls one stage of heating and one stage of cooling, which covers most single-speed furnace and AC systems. 2H/2C supports two-stage heating and two-stage cooling, common in dual-fuel systems (heat pump plus gas furnace) or two-stage equipment. Using a 1H/1C thermostat on a two-stage system means the second stage will never activate.

How do I know if my thermostat is bad?

Common signs include a blank display, the system not responding to temperature changes, short-cycling (turning on and off rapidly), or incorrect temperature readings. Before replacing the thermostat, check the batteries, verify the circuit breaker is on, and ensure the furnace door switch is closed. You can test by jumping the R and W terminals at the furnace to see if heating starts without the thermostat.
