OEM Carrier Flame Sensor Rod for PG92SCS60080CAAA Gas Furnace

The flame sensor proves to the control board that a flame is actually burning at the burners once the gas valve opens. It works by flame rectification: the rod passes a microscopic DC current through the flame, and if the board doesn't see that current it cuts the gas within seconds as a safety. As the rod accumulates oxide and silica scale — or simply ages — the signal weakens. The furnace then lights, burns for a few seconds, and shuts off, cycling like this three or four times before going into hard lockout and leaving you with cold air from the registers. This OEM Carrier sensor uses the correct Kanthal/stainless rod length and tip geometry for the PG92 platform, calibrated to the board's microamp window (commonly 1–6 µA DC). A clean, in-spec rod holds a strong steady signal; a worn or wrong-length rod reads low and trips the safety even when combustion is healthy. Why OEM matters: aftermarket rods frequently use inconsistent alloys and off-spec lengths, so they sit outside the flame envelope or read erratically — producing the exact intermittent short-cycling you're trying to cure. The matched OEM part restores a reliable signal. Install difficulty: 2 of 5. Tools: 1/4" nut driver, a Scotch-Brite pad or fine emery cloth, and a multimeter on the microamp DC scale to confirm the signal after installation. SAFETY: always shut off power at the furnace disconnect before removing the sensor; the burner compartment is live during operation. Ships same business day from our stocked warehouse on orders placed before 3 PM CST. Backed by a 1-year OEM warranty and 30-day hassle-free returns on uninstalled parts.

Compatibility

This part is compatible with Carrier model PG92SCS60080CAAA. Always verify the part number against your unit's data plate before ordering.

Why Choose OEM?

OEM parts are manufactured to the exact factory specifications for your unit. Generic aftermarket alternatives may fit physically but often use lower-rated components that reduce equipment life and void manufacturer warranties. When the cost difference between OEM and generic is $10-30, the OEM part is always the smarter investment on a system worth $5,000-$15,000.
