What MFD capacitor do I need for my Tempstar AC?

The correct replacement for Tempstar model TCA924GKA100 — Single Run | Ships Today is this exact part. It is the factory-specified replacement with exact OEM specifications. Using a part with different specifications can cause equipment damage or void your warranty. You can verify this by checking the data plate on your Tempstar equipment which lists the model number TCA924GKA100 — Single Run | Ships Today.

My AC hums but will not start. What part do I need?

An AC that hums but will not start is the classic symptom of a failed capacitor. The capacitor provides the electrical boost needed to start the compressor and fan motors. When it fails, you hear the hum of the motor trying to start but it cannot overcome inertia. Other symptoms include the fan spinning slowly, the AC cycling on and off rapidly, or a visibly swollen or leaking capacitor. Replacement cost: $15 to $80 for the part, DIY in 30 minutes.

Is this capacitor compatible with Bryant or Payne systems too?

Many Tempstar parts are cross-compatible with Bryant and Payne systems since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across multiple brand labels with different model numbers. To verify cross-compatibility, check your Bryant or Payne equipment service manual for cross-compatible part numbers, or contact info@nationalhvacparts.com with your model number for confirmation.

Tempstar

Tempstar Run Capacitor 35 MFD 440V for TCA924GKA100 — Single Run | Ships Today

Name: Tempstar Run Capacitor 35 MFD 440V for TCA924GKA100 — Single Run | Ships Today
Brand: Tempstar
SKU: 1185067-GEN
Price: 18.95 USD
Availability: InStock

SKU: 1185067-GEN Brand: Tempstar

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

Texas CMBL #19328542014

SAM.gov Registered

Govt POs Accepted

Overview

This OEM single run capacitor (part number 1185067) provides the steady phase shift that keeps the compressor or condenser fan motor turning efficiently on your Tempstar TCA924GKA100. Rated 35 MFD at 440V, it stores and releases the energy the motor needs to run smoothly under load. A failing capacitor is the single most common HVAC service call — symptoms include a humming unit that won't start, a fan that needs a push to spin, hard starting, high amp draw, and a bulged or leaking capacitor top. Installing the correct 35 MFD / 440V OEM part restores full starting torque and protects the motor windings from overheating.

Specifications

Spec	Value
Part Number	1185067
Type	Single Run Capacitor
Brand	Tempstar (ICP / Heil family)
Capacitance	35 MFD
Voltage Rating	440V
Fitment	OEM Replacement

Compatibility

Built for the Tempstar TCA924GKA100 and the ICP / Heil / Comfortmaker condensing units that share this 35 MFD 440V run capacitor. A 440V capacitor can safely replace a 370V unit of the same MFD, but the MFD value must match exactly.

Installation Guide

Safety First — Disconnect power and verify zero voltage, then discharge the capacitor across its terminals with an insulated resistor before touching it.
Access — Remove the service panel on the condensing unit.
Document — Photograph all terminal wiring before disconnecting.
Remove — Note the terminal markings, disconnect the leads, and release the mounting strap.
Install — Secure the new capacitor and reconnect each lead to its matching terminal per your photo.
Test — Restore power and confirm the motor starts instantly and runs without humming.

Signs You Need a Replacement

Motor hums but won't start, or needs a manual push to spin
Bulged, swollen, or leaking capacitor top
High amp draw or frequent breaker trips
Intermittent cooling or hard starting

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.

Shipping Information

Orders placed before 3PM CST ship same business day
Standard delivery: 2-5 business days
Express shipping available at checkout
Free shipping on orders over $75
Tracking number emailed upon shipment

Return Policy

30-day returns on unused parts in original packaging
Electrical parts (capacitors, contactors, control boards) are final sale once installed
Email info@nationalhvacparts.com to initiate a return
Refunds processed within 5-7 business days

Tempstar Run Capacitor 35 MFD 44...

$18.95

Frequently Asked Questions

Does this Capacitor fit my Tempstar TCA924GKA100 — Single Run | Ships Today?

Yes. This is the factory-specified OEM capacitor for the Tempstar TCA924GKA100 — Single Run | Ships Today. It is a direct drop-in replacement that fits without modification. Always verify the model number on your equipment nameplate before ordering.

How do I replace the capacitor on my Tempstar TCA924GKA100 — Single Run | Ships Today?

Difficulty: Easy (20–30 min)
Step 1: Turn off power at breaker. Step 2: Open condensing unit panel. Step 3: Photograph the old capacitor wiring (Common/Herm/Fan). Step 4: Discharge old capacitor with insulated screwdriver. Step 5: Disconnect and remove old capacitor. Step 6: Mount new capacitor, reconnect wires to matching terminals. Step 7: Close panel, restore power, test. Tools: screwdriver, needle-nose pliers.

My AC hums but won’t start. What part do I need?

An AC that hums but won’t start is the classic symptom of a failed capacitor. The capacitor provides the electrical boost to start the compressor. When it fails, you hear humming but the motor can’t overcome inertia. Other symptoms: fan spinning slowly, AC cycling on/off rapidly, or a visibly swollen capacitor. Fix: replace capacitor ($15–$80 DIY, 30 min).

Is this capacitor compatible with Bryant or Payne too?

Many Tempstar parts are cross-compatible with Bryant and Payne since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across brand labels with different model numbers. To verify: check your Bryant or Payne equipment service manual for cross-compatible part numbers, or email info@nationalhvacparts.com with your model number.

Should I use OEM or aftermarket for my Tempstar capacitor?

OEM strongly recommended. OEM capacitors have ±6% MFD tolerance vs aftermarket ±10%. The looser tolerance causes motor winding stress, higher temps, and shorter compressor life. Price difference is only $10–$20 — OEM is the clear value choice.

How fast does National HVAC Parts ship?

Orders placed before 3:00 PM CST ship the same business day. Standard delivery is 2–5 business days anywhere in the continental United States. Express shipping available at checkout. We ship from Houston, TX to all 50 states. 30-day return policy on all parts.
