Tempstar PTAC Thermostat for TEB15K50SPA — OEM Control with Knob | Ships Today

Overview

This OEM PTAC thermostat kit for the Tempstar TEB15K50SPA includes the thermostat control (part #1058517) and its matching adjustment knob (part #1058437). As the control center of the packaged terminal unit, the thermostat reads room temperature and tells the system when to heat, cool, or idle the fan. PTAC thermostats endure constant cycling in hospitality and multi-family settings; worn contacts and drifting calibration eventually cause nonstop running, short-cycling, or a unit that won't start. A new thermostat and knob restore accurate, reliable temperature control.

Specifications

Compatibility

Direct OEM replacement for the Tempstar TEB15K50SPA PTAC and related ICP / Heil / Tempstar TEB15-series packaged terminal units that use the 1058517 thermostat and 1058437 knob. Verify your existing control's part number before ordering.

Installation Guide

1. Safety First — Disconnect power at the breaker and verify zero voltage with a multimeter.
2. Access — Remove the front grille and control-panel cover to expose the thermostat.
3. Document — Photograph every wire on the thermostat terminals before disconnecting.
4. Remove — Pull off the old knob, disconnect the thermostat leads, and unmount the control body.
5. Install — Mount the new thermostat, reconnect each wire per your photo, and press the new knob onto the shaft.
6. Test — Restore power and confirm the unit cycles heating, cooling, and fan correctly across the knob's range.

Signs You Need a Replacement

• Unit runs continuously and never reaches setpoint
• No response to temperature adjustments
• Cracked, loose, or missing control knob
• Erratic cycling or temperature swings

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. National HVAC Parts fitment guarantee.
