Tempstar PTAC Thermostat for TEB07K34DCA — Low-Temp Knob Control Kit | Ships Today
OEM Guaranteed
Same-Day Ship
30-Day Returns
Secure Checkout
Overview
This OEM PTAC thermostat kit provides the temperature control for the Tempstar TEB07K34DCA packaged terminal air conditioner. It combines the rotary knob (OEM 1058437), the standard PTAC thermostat (OEM 1058517), and the low-temperature thermostat (OEM 1059022) that protects the unit in freeze-prone applications by preventing operation below safe temperatures. These are 24V low-voltage controls. A failed PTAC thermostat causes the unit to run continuously, fail to start, or ignore the knob setting; a failed low-temp thermostat can allow nuisance cutouts or, worse, defeat freeze protection. Knobs on high-use hospitality units commonly strip or crack and need replacement well before the thermostat body wears out.
Specifications
| Spec | Value |
|---|---|
| Part Numbers | 1058437 (Knob), 1058517 (Thermostat), 1059022 (Low-Temp Thermostat) |
| Type | PTAC Rotary Thermostat w/ Low-Temp |
| Brand | Tempstar (ICP / Heil) |
| Control Voltage | 24V |
| Fit | OEM Direct Replacement |
Compatibility
Engineered for the Tempstar TEB07K34DCA PTAC and shared across the ICP/Heil/Tempstar TEB07K34 family. Verify the part numbers against the unit's rating plate before installing.
Installation Guide
- Safety First — Disconnect power at the unit and breaker, then verify zero voltage with a multimeter.
- Access — Slide off the PTAC front cover to reach the control box.
- Document — Photograph all thermostat and low-temp sensor wiring before disconnecting.
- Remove — Pull the old knob, release the thermostat clips/screws, and disconnect the spade terminals.
- Install — Mount the new thermostats, route the low-temp sensor to its original location, reconnect per your photo, and press on the new knob.
- Test — Restore power, cycle through the range, and confirm cooling, heating, and low-temp protection respond correctly.
Signs You Need a Replacement
- Unit runs nonstop or won't start regardless of knob position
- Nuisance shutdowns or no freeze protection in cold ambient
- Cracked, loose, or spinning knob that won't engage the stem
- Erratic temperature swings or short-cycling
