Overview
This OEM high and low refrigerant pressure switch set — part 1184656 (Pressure Switch, High) and 1184655 (Pressure Switch, Low) — protects the Tempstar TSH548GKA100 compressor from damaging operating conditions. The high-pressure switch opens the control circuit and shuts the compressor down if discharge pressure climbs too high (dirty condenser, failed fan, overcharge). The low-pressure switch opens on a loss of charge or restricted suction to prevent the compressor from running in a vacuum. Both are normally-closed safety devices wired in the 24V control circuit.
A failed-open or chattering switch will lock the system out and prevent the compressor from running even when conditions are normal; a failed-closed switch removes safety protection. Symptoms include a compressor that won't start, intermittent lockouts, or short-cycling on the safety circuit.
Specifications
| Spec | Value |
|---|---|
| Part Numbers | 1184656 (high), 1184655 (low) |
| Type | Refrigerant Pressure Switch (High & Low) |
| Brand | Tempstar (ICP / Heil) |
| Circuit | 24V control, normally closed |
| Function | Compressor high/low pressure protection |
| Fitment | OEM |
Compatibility
Built for the Tempstar TSH548GKA100 and shared across ICP-family units (Heil, Comfortmaker, Tempstar) using the same high/low pressure protection. Match the switch trip ratings and fitting/connector style to your existing parts before ordering.
Installation Guide
- Safety First — Disconnect power at the disconnect and breaker, then verify zero voltage with a multimeter.
- Access — Remove the condenser service panel to reach the refrigerant lines and switches.
- Document — Photograph the switch wiring and note which switch is high vs. low.
- Remove — Disconnect the 24V leads; switches on Schrader-style ports thread off without recovery, while brazed/sweat switches require refrigerant recovery first.
- Install — Install the new switch on its matching port, reconnect the 24V leads per your photo, and check for leaks.
- Test — Restore power, run the system, and confirm normal pressures with no nuisance lockout.
Signs You Need a Replacement
- Compressor won't start and the control circuit reads open at the switch.
- Intermittent high- or low-pressure lockouts under normal conditions.
- Short-cycling traced to the safety/pressure circuit.
- Switch fails a continuity check at known-good pressures.
