This OEM pressure switch set protects the Tempstar TSH524GKA100 by monitoring refrigerant system pressure and shutting the compressor down before damage occurs. The set includes the high-pressure switch (Part No. 1184656) and the low-pressure switch (Part No. 1184655). The high-pressure switch opens if discharge pressure climbs too high — typically from a dirty condenser coil, failed fan, or overcharge — while the low-pressure switch opens on a loss of charge or restricted flow. Each switch is wired in the 24V control circuit, so a tripped switch interrupts the contactor coil and stops the unit. Faulty or stuck switches cause nuisance lockouts, no-cool calls, or a compressor that fails to start even though everything else checks out.

Specifications

Compatibility

Factory-matched to the Tempstar TSH524GKA100 heat pump and the broader ICP/Heil/Comfortmaker outdoor lineup that uses the 1184656 high and 1184655 low pressure switches. Confirm your unit uses both a hi and lo switch before ordering the set.

Installation Guide

1. Safety First — Disconnect power at the outdoor disconnect and breaker, then verify zero voltage with a multimeter.
2. Access — Remove the outdoor unit's electrical and refrigerant access panel.
3. Document — Photograph the 24V wiring on each switch before disconnecting.
4. Remove — These are typically Schrader-mounted switches; back out the old switch while a service valve or recovery setup controls refrigerant loss, or replace on a recovered system.
5. Install — Thread on the new switch with a fresh seal, then reconnect the control wires per your photo.
6. Test — Restore power, run a cooling cycle, and verify both switches stay closed under normal operating pressures.

Signs You Need a Replacement

• Compressor locks out or short-cycles with no obvious pressure fault.
• Unit won't start and the control board flashes a pressure-switch fault.
• Switch fails a continuity test at normal operating pressure.
• Repeated nuisance high- or low-pressure trips after the system is verified good.
