Tempstar Pressure Switch Kit (HI & LO) for TSH530GKA200 — 24V Heat Pump | Ships Today

Name: Tempstar Pressure Switch Kit (HI & LO) for TSH530GKA200 — 24V Heat Pump | Ships Today
Brand: Tempstar
SKU: 1184656-GEN
Price: 34.95 USD
Availability: InStock

SKU: 1184656-GEN Brand: Tempstar

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

Texas CMBL #19328542014

SAM.gov Registered

Govt POs Accepted

Overview

This is a genuine OEM high-pressure and low-pressure switch set for the Tempstar TSH530GKA200 heat pump. These 24V refrigerant pressure switches guard the compressor by opening the control circuit when discharge pressure climbs too high (high-pressure switch, OEM 1184656) or suction pressure falls too low (low-pressure switch, OEM 1184655). A bad switch shows up as short-cycling, a no-start condition, or repeated safety lockouts. Replacing the pair restores dependable compressor protection.

Specifications

Spec	Value
Part Numbers	1184656 (HI), 1184655 (LO)
Type	Refrigerant Pressure Switch (High & Low)
Brand	Tempstar / Heil / ICP
Control Voltage	24V
Function	Compressor Safety Lockout
Fit	OEM Direct Replacement

Compatibility

Designed for the Tempstar TSH530GKA200 heat pump and shared ICP/Heil/Comfortmaker chassis using the same controls. Match the part numbers on your existing switches before ordering.

Installation Guide

Safety First — Disconnect power and verify zero voltage with a multimeter.
Access — Remove the service panel to expose the refrigerant lines and control wiring.
Document — Photograph each wire connection before disconnecting.
Remove — Recover or isolate refrigerant as required, then remove the failed switch and its leads.
Install — Mount the new switch, seal the fitting, and reconnect the leads per your photo.
Test — Restore power and confirm the compressor runs and the safeties hold at normal pressures.

Signs You Need a Replacement

Compressor trips on a high- or low-pressure safety fault.
Unit short-cycles or will not start in heating or cooling.
Switch fails to close at normal operating pressure.
Corrosion, refrigerant weep, or damaged terminals at the switch.

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.

Shipping Information

Orders placed before 3PM CST ship same business day
Standard delivery: 2-5 business days
Express shipping available at checkout
Free shipping on orders over $75
Tracking number emailed upon shipment

Return Policy

30-day returns on unused parts in original packaging
Electrical parts (capacitors, contactors, control boards) are final sale once installed
Email info@nationalhvacparts.com to initiate a return
Refunds processed within 5-7 business days

Tempstar Pressure Switch Kit (HI...

$34.95
