Tempstar Low Pressure Switch for TCH924GKA300 — OEM 1184655 | Ships Today

Overview

The Tempstar low pressure switch (OEM part 1184655) is a refrigerant-side safety control that protects your compressor by monitoring suction-line pressure. When system pressure drops below the factory cut-out setpoint — caused by a refrigerant leak, restricted metering device, or low ambient charge migration — the switch opens, interrupting the 24V control circuit and shutting down the compressor before damage occurs. As pressure recovers, the auto-reset contacts close and normal operation resumes. A failed pressure switch is a leading cause of intermittent no-cool and short-cycling complaints.

Specifications

Compatibility

Engineered as a direct-fit OEM replacement for Tempstar model TCH924GKA300 and shared ICP/Heil/Comfortmaker heat pump platforms using the same chassis. Always confirm your existing part number before ordering.

Installation Guide

1. Safety First — Disconnect power at the disconnect and breaker, then verify zero voltage with a multimeter.
2. Access — Remove the unit service panel.
3. Document — Photograph the wire connections before disconnecting.
4. Remove — Recover refrigerant if required, disconnect the two control leads, and unthread or unclip the failed switch from its Schrader-style fitting.
5. Install — Thread on the new switch, reconnect the control leads per your photo, and leak-check the joint.
6. Test — Restore power and verify the compressor energizes and the system holds pressure.

Signs You Need a Replacement

• Compressor short-cycles or refuses to start in cool/heat mode
• Intermittent no-cool that clears after sitting
• Switch fails to close even with verified-good system pressure
• Visible corrosion or pitted contacts on the switch terminals

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.
