Tempstar Hot Surface Igniter for T9UHX060F12A2 — HSI Furnace Ignitor | Ships Today

Overview

This is the OEM hot surface igniter (OEM part 1172533, HSI) for the Tempstar T9UHX060F12A2 gas furnace, used with the matching VR8205S snap-mount gas valve (OEM part 1175705). The igniter is an electrically heated element that glows orange-hot to light the gas at the burners on every heat call. It is among the most common furnace wear items because repeated heat cycling makes the element brittle until it cracks. On failure, the inducer and blower may still run but the burners never light, and the control board generally locks out after several failed ignition attempts.

Specifications

Compatibility

Direct-fit replacement for the Tempstar T9UHX060F12A2 furnace and compatible ICP/Heil/Comfortmaker models using the 1172533 hot surface igniter. Confirm your existing igniter mounting style and connector match before installing.

Installation Guide

1. Safety First — Shut off gas and disconnect power at the furnace switch and breaker, then verify zero voltage with a multimeter.
2. Access — Remove the burner-compartment service panel.
3. Document — Photograph the igniter position, bracket, and wire connector before removal.
4. Remove — Unplug the igniter connector and remove the mounting screw, handling the old element only by its ceramic base.
5. Install — Mount the new igniter without touching the element surface with bare fingers, then reconnect the wiring per your photo.
6. Test — Restore gas and power, then watch a full ignition cycle to confirm the element glows and the burners light.

Signs You Need a Replacement

• Furnace cycles but burners never ignite.
• Control board locks out after 3 failed ignition tries.
• Igniter element is visibly cracked, blistered, or no longer glows.
• No resistance reading across the igniter terminals.
