Overview
This OEM pressure switch set covers both the high-pressure switch (part #1184656) and low-pressure switch (part #1184655) for the Tempstar TSH560GKA200 heat pump. These 24V safety switches monitor refrigerant pressure and open the control circuit to shut the compressor down before a dangerous over-pressure or loss-of-charge condition can cause damage. The HI switch protects against blocked condenser airflow, overcharge, or a failed outdoor fan; the LO switch protects against undercharge, a leak, or a frozen indoor coil. When a switch fails or sticks, the unit may short-cycle, lock out on a safety fault, or refuse to start the compressor at all.
Specifications
| Spec | Value |
|---|---|
| Part Numbers | 1184656 (HI), 1184655 (LO) |
| Type | High & Low Pressure Switch |
| Brand | Tempstar |
| Control Voltage | 24V |
| Calibration | Factory-set, auto-reset |
| Application | Heat Pump Refrigerant Circuit |
Compatibility
Direct OEM replacements for the Tempstar TSH560GKA200 series and equivalent Heil, Comfortmaker, and ICP-built heat pumps that used switches 1184656 and 1184655. Verify the part number stamped on your existing switch and the spade terminal orientation before installing.
Installation Guide
- Safety First — Disconnect power at the outdoor disconnect and verify zero voltage with a multimeter.
- Access — Remove the outdoor service panel to reach the refrigerant lines and switch mounting points.
- Document — Photograph the 24V wire leads on each switch before disconnecting.
- Remove — These are typically Schrader-mounted; back the switch off the port and let the depressor reseat to minimize refrigerant loss, or recover the charge first.
- Install — Thread the new switch onto its port, snug to spec, and reconnect the 24V leads per your photo.
- Test — Restore power, confirm the control circuit closes, and verify the unit starts and runs without tripping a safety lockout.
Signs You Need a Replacement
- Compressor will not start while the fan runs normally
- Unit short-cycles or locks out on a pressure fault code
- Switch fails a continuity test at normal operating pressure
- Visible corrosion, cracked housing, or a stuck open/closed switch
