Tempstar Control Board for TXA624GKA100 — ComfortAlert Diagnostic Module | Ships Today

Name: Tempstar Control Board for TXA624GKA100 — ComfortAlert Diagnostic Module | Ships Today
Brand: Tempstar
SKU: 1177402-GEN
Price: 169.00 USD
Availability: InStock

SKU: 1177402-GEN Brand: Tempstar

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

Texas CMBL #19328542014

SAM.gov Registered

Govt POs Accepted

Overview

This is a genuine OEM ComfortAlert control board (OEM #1177402) for the Tempstar TXA624GKA100 condensing unit. The ComfortAlert diagnostic module monitors compressor and control-circuit operation, detecting faults such as low/high voltage, locked rotor, open circuit, and short cycling, then flashes a fault code to speed troubleshooting. A failed board can leave the system unable to start, short cycling, running continuously, or reporting erratic codes. Installing the correct OEM board restores reliable 24V control and accurate fault reporting.

Specifications

Spec	Value
Part Number	1177402
Type	ComfortAlert Diagnostic Control Board
Brand	Tempstar (ICP / Heil)
Control Voltage	24V
Fits Model	TXA624GKA100
Fitment	OEM Replacement

Compatibility

Engineered for the Tempstar TXA624GKA100 air conditioning condensing unit and shared across ICP, Heil, Comfortmaker, and other ICP-family units that originally used part 1177402. Always confirm the OEM number on your existing board before ordering.

Installation Guide

Safety First — Disconnect power at the disconnect and breaker, then verify zero voltage with a multimeter.
Access — Remove the control-access service panel on the condensing unit.
Document — Photograph every wire and connector on the board before disconnecting anything.
Remove — Label and disconnect the low-voltage and line connections, then unclip or unscrew the failed board from its standoffs.
Install — Mount the new board to the same standoffs and reconnect each wire to match your photo.
Test — Restore power, call for cooling, and confirm normal startup and a clear diagnostic LED.

Signs You Need a Replacement

System won't start or randomly short cycles
Erratic, continuous, or missing diagnostic flash codes
Burn marks, corrosion, or scorching on the board
Compressor or fan not responding to thermostat calls

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.

Shipping Information

Orders placed before 3PM CST ship same business day
Standard delivery: 2-5 business days
Express shipping available at checkout
Free shipping on orders over $75
Tracking number emailed upon shipment

Return Policy

30-day returns on unused parts in original packaging
Electrical parts (capacitors, contactors, control boards) are final sale once installed
Email info@nationalhvacparts.com to initiate a return
Refunds processed within 5-7 business days

Tempstar Control Board for TXA62...

$169.00

Frequently Asked Questions

Does this Control Board fit my Tempstar TXA624GKA100 — ComfortAlert Diagnostic Module | Ships Today?

Yes. This is the factory-specified OEM control board for the Tempstar TXA624GKA100 — ComfortAlert Diagnostic Module | Ships Today. It is a direct drop-in replacement that fits without modification. Always verify the model number on your equipment nameplate before ordering.

How do I replace the control board on my Tempstar TXA624GKA100 — ComfortAlert Diagnostic Module | Ships Today?

Difficulty: Advanced (1–2 hrs)
Step 1: Turn off breaker. Step 2: PHOTOGRAPH all wire connections before touching anything. Step 3: Label each wire with tape. Step 4: Disconnect all wires, remove old board. Step 5: Mount new board, reconnect all wires matching your photo exactly. Step 6: Restore power and test all modes. Exact part number match is critical.

My HVAC system is completely dead. What could be wrong?

Completely dead HVAC (no LED on board) = failed control board or blown fuse. Check board fuse first (3A or 5A, costs $1–$5). If fuse is good and board has power but no LED, board is dead. Always photograph wiring before replacing.

Is this control board compatible with Bryant or Payne too?

Many Tempstar parts are cross-compatible with Bryant and Payne since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across brand labels with different model numbers. To verify: check your Bryant or Payne equipment service manual for cross-compatible part numbers, or email info@nationalhvacparts.com with your model number.

Should I use OEM or aftermarket for my Tempstar control board?

OEM essential. Control boards are model-specific with precise firmware and connector layouts. Aftermarket boards rarely match all functions and can cause intermittent failures or safety issues. Always match the exact OEM part number.

How fast does National HVAC Parts ship?

Orders placed before 3:00 PM CST ship the same business day. Standard delivery is 2–5 business days anywhere in the continental United States. Express shipping available at checkout. We ship from Houston, TX to all 50 states. 30-day return policy on all parts.
