Tempstar

Tempstar Comfort Alert Control Board for TXA661GKA100 — Diagnostic Module | Ships Today

Name: Tempstar Comfort Alert Control Board for TXA661GKA100 — Diagnostic Module | Ships Today
Brand: Tempstar
SKU: 1177402-GEN
Price: 189.00 USD
Availability: InStock

SKU: 1177402-GEN Brand: Tempstar

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

Texas CMBL #19328542014

SAM.gov Registered

Govt POs Accepted

Overview

This OEM Comfort Alert control board (part 1177402) is the diagnostic and protection module for the Tempstar TXA661GKA100. It continuously monitors compressor performance and flashes coded faults for conditions like low voltage, locked rotor, open circuit, short cycling, and missing run capacitor — turning hours of guesswork into a quick LED readout. When this board fails, the unit may lose compressor protection, refuse to start, or throw erratic fault codes. A failed board commonly results from voltage surges, lightning, or a contactor/compressor fault that damages the module.

Specifications

Spec	Value
Part Number	1177402
Type	Comfort Alert Diagnostic Control Board
Brand	Tempstar
Control Voltage	24 VAC
Function	Compressor monitoring & fault diagnostics

Compatibility

Direct-fit replacement for the Tempstar TXA661GKA100 and matching ICP/Heil condensing units equipped with the Comfort Alert diagnostic system. Match the printed part number on your existing board before ordering.

Installation Guide

Safety First — Disconnect power at the disconnect and breaker, then verify zero voltage with a multimeter.
Access — Remove the condenser electrical service panel.
Document — Photograph every low-voltage and sensor lead before disconnecting.
Remove — Unplug the harness connectors and unclip or unscrew the old board.
Install — Mount the new board and reconnect each connector per your photo.
Test — Restore power and confirm a steady status LED with no active fault codes.

Signs You Need a Replacement

No status LED or a dead diagnostic display.
Compressor won't start despite a valid cooling call.
Random or nonsensical fault codes flashing.
Loss of compressor protection after a power surge or strike.

Shipping & Returns

Ships same day on orders placed before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.

Shipping Information

Orders placed before 3PM CST ship same business day
Standard delivery: 2-5 business days
Express shipping available at checkout
Free shipping on orders over $75
Tracking number emailed upon shipment

Return Policy

30-day returns on unused parts in original packaging
Electrical parts (capacitors, contactors, control boards) are final sale once installed
Email info@nationalhvacparts.com to initiate a return
Refunds processed within 5-7 business days

Tempstar Comfort Alert Control B...

$189.00
