What are the specs for this Pressure Switch?

The correct replacement for Goodman model ACES800603AXAA — 0130F00504 is this exact part. It is the factory-specified replacement with exact OEM specifications. Using a part with different specifications can cause equipment damage or void your warranty. You can verify this by checking the data plate on your Goodman equipment which lists the model number ACES800603AXAA — 0130F00504.

Is this pressure switch compatible with Bryant or Payne systems too?

Many Goodman parts are cross-compatible with Bryant and Payne systems since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across multiple brand labels with different model numbers. To verify cross-compatibility, check your Bryant or Payne equipment service manual for cross-compatible part numbers, or contact info@nationalhvacparts.com with your model number for confirmation.

Goodman

OEM Goodman 0.60" NO Pressure Switch for ACES800603AXAA — 0130F00504

Name: OEM Goodman 0.60" NO Pressure Switch for ACES800603AXAA — 0130F00504
Brand: Goodman
SKU: 0130F00504-GEN
Price: 24.95 USD
Availability: InStock

SKU: 0130F00504-GEN Brand: Goodman

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

Texas CMBL #19328542014

SAM.gov Registered

Govt POs Accepted

The Goodman 0130F00504 is a genuine OEM air-proving pressure switch (orange, normally open, rated at -0.60" water column) designed for the ACES800603AXAA gas furnace. It confirms that the draft inducer is moving combustion air before the control board energizes the igniter and gas valve. A weak or stuck pressure switch is one of the most frequent causes of a furnace that flashes a fault code and refuses to light — replacing it with the correct factory part restores safe, reliable ignition.

Specifications

Part Number: 0130F00504
Type: Air-proving / draft pressure switch
Set Point: -0.60" WC (water column)
Contact Configuration: Normally Open (NO)
Color Code: Orange
Brand: Goodman / Amana
Fits: ACES800603AXAA furnace

OEM vs. Generic

This genuine OEM Goodman switch is set to the exact -0.60" WC trip point this furnace requires. The set point and NO/NC configuration are safety-critical: a generic switch with the wrong rating may prove draft when airflow is actually insufficient, creating a hazardous condition. Always match OEM specs on pressure switches.

Installation

Difficulty: Easy to Moderate. Power off, photograph the hose routing, transfer the silicone tubing to the new switch exactly as found, reconnect the electrical terminals, and remount. About 20 minutes. Verify the hose is free of condensate and the port is clear. If unsure, consult a licensed HVAC technician.

Shipping Information

Orders placed before 3PM CST ship same business day
Standard delivery: 2-5 business days
Express shipping available at checkout
Free shipping on orders over $75
Tracking number emailed upon shipment

Return Policy

30-day returns on unused parts in original packaging
Electrical parts (capacitors, contactors, control boards) are final sale once installed
Email info@nationalhvacparts.com to initiate a return
Refunds processed within 5-7 business days

OEM Goodman 0.60" NO Pressure Sw...

$24.95

Frequently Asked Questions

Does this Pressure Switch fit my Goodman ACES800603AXAA — 0130F00504?

Yes. This is the factory-specified OEM pressure switch for the Goodman ACES800603AXAA — 0130F00504. It is a direct drop-in replacement that fits without modification. Always verify the model number on your equipment nameplate before ordering.

How do I replace the pressure switch on my Goodman ACES800603AXAA — 0130F00504?

Difficulty: Medium (20–30 min)
Step 1: Turn off power. Step 2: Locate pressure switch near draft inducer. Step 3: Note tubing orientation. Step 4: Disconnect tubing and wires. Step 5: Remove screw, install new switch. Step 6: Reconnect tubing and wires, restore power.

My furnace shows a pressure switch error. What do I replace?

Furnace LED showing pressure switch error = switch not detecting draft inducer airflow. Try first: clear the rubber tubing to the switch (often clogged with condensation). If problem persists, replace the pressure switch.

Is this pressure switch compatible with Bryant or Payne too?

Many Goodman parts are cross-compatible with Bryant and Payne since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across brand labels with different model numbers. To verify: check your Bryant or Payne equipment service manual for cross-compatible part numbers, or email info@nationalhvacparts.com with your model number.

Should I use OEM or aftermarket for my Goodman pressure switch?

OEM recommended for reliability and warranty compatibility. OEM parts match exact factory specifications for proper fit, performance, and safety. While aftermarket alternatives cost less upfront, the risk of improper fit and reduced lifespan usually makes OEM the better value long-term.

How fast does National HVAC Parts ship?

Orders placed before 3:00 PM CST ship the same business day. Standard delivery is 2–5 business days anywhere in the continental United States. Express shipping available at checkout. We ship from Houston, TX to all 50 states. 30-day return policy on all parts.
