What MFD capacitor do I need for my ICP AC?

The correct replacement for ICP model WFSR080C060A2 — With Strap | Ships Today is this exact part. It is the factory-specified replacement with exact OEM specifications. Using a part with different specifications can cause equipment damage or void your warranty. You can verify this by checking the data plate on your ICP equipment which lists the model number WFSR080C060A2 — With Strap | Ships Today.

My AC hums but will not start. What part do I need?

An AC that hums but will not start is the classic symptom of a failed capacitor. The capacitor provides the electrical boost needed to start the compressor and fan motors. When it fails, you hear the hum of the motor trying to start but it cannot overcome inertia. Other symptoms include the fan spinning slowly, the AC cycling on and off rapidly, or a visibly swollen or leaking capacitor. Replacement cost: $15 to $80 for the part, DIY in 30 minutes.

ICP

ICP Run Capacitor 35 MFD 370V for WFSR080C060A2 — With Strap | Ships Today

Name: ICP Run Capacitor 35 MFD 370V for WFSR080C060A2 — With Strap | Ships Today
Brand: ICP
SKU: 1184895
Price: 24.64 USD
Availability: InStock

SKU: 1184895 Brand: ICP

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

Texas CMBL #19328542014

SAM.gov Registered

Govt POs Accepted

Overview

This OEM single-run capacitor kit for the ICP/Tempstar/Heil WFSR080C060A2 includes a 35 MFD, 370V oval run capacitor (part number 1184895) and its matching mounting strap (part number 1014315). The run capacitor provides the constant phase-shifted current that keeps the blower motor turning efficiently. Rated at 35 microfarads and 370 volts, a weak or failed capacitor causes the motor to overheat, hum without starting, or trip on thermal overload. Capacitors are a wear item that lose capacitance over time, especially in hot equipment rooms. The included strap secures the capacitor against the cabinet wall to prevent vibration damage.

Specifications

Spec	Value
Capacitor Part Number	1184895
Strap Part Number	1014315
Type	Single-Run Capacitor
Brand	ICP / Tempstar / Heil
Rating	35 MFD
Voltage	370V
Shape	Oval
Fitment	OEM

Compatibility

Factory run capacitor for the ICP/Tempstar/Heil WFSR080C060A2 and ICP-family equipment specifying a 35 MFD, 370V oval capacitor. A 370V capacitor may also be used to replace a 440V unit of the same MFD, but never the reverse. Confirm MFD and voltage match before installing.

Installation Guide

Safety First — Disconnect power at the switch and breaker, verify zero voltage with a multimeter, then discharge the capacitor across its terminals.
Access — Remove the blower-compartment service panel.
Document — Photograph every capacitor lead before disconnecting.
Remove — Loosen the strap, slide out the old capacitor, and disconnect the leads.
Install — Connect leads to the matching terminals, seat the new capacitor in the strap, and tighten it against the cabinet.
Test — Restore power and confirm the blower starts instantly and runs smoothly.

Signs You Need a Replacement

Blower hums but will not start, or starts slowly
Motor overheats or trips on thermal overload
Bulged, leaking, or domed capacitor top
Capacitance reads below the rated 35 MFD on a meter

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.

Shipping Information

Orders placed before 3PM CST ship same business day
Standard delivery: 2-5 business days
Express shipping available at checkout
Free shipping on orders over $75
Tracking number emailed upon shipment

Return Policy

30-day returns on unused parts in original packaging
Electrical parts (capacitors, contactors, control boards) are final sale once installed
Email info@nationalhvacparts.com to initiate a return
Refunds processed within 5-7 business days

ICP Run Capacitor 35 MFD 370V fo...

$24.64

Frequently Asked Questions

Does this Capacitor fit my ICP WFSR080C060A2 — With Strap | Ships Today?

Yes. This is the factory-specified OEM capacitor for the ICP WFSR080C060A2 — With Strap | Ships Today. It is a direct drop-in replacement that fits without modification. Always verify the model number on your equipment nameplate before ordering.

How do I replace the capacitor on my ICP WFSR080C060A2 — With Strap | Ships Today?

Difficulty: Easy (20–30 min)
Step 1: Turn off power at breaker. Step 2: Open condensing unit panel. Step 3: Photograph the old capacitor wiring (Common/Herm/Fan). Step 4: Discharge old capacitor with insulated screwdriver. Step 5: Disconnect and remove old capacitor. Step 6: Mount new capacitor, reconnect wires to matching terminals. Step 7: Close panel, restore power, test. Tools: screwdriver, needle-nose pliers.

My AC hums but won’t start. What part do I need?

An AC that hums but won’t start is the classic symptom of a failed capacitor. The capacitor provides the electrical boost to start the compressor. When it fails, you hear humming but the motor can’t overcome inertia. Other symptoms: fan spinning slowly, AC cycling on/off rapidly, or a visibly swollen capacitor. Fix: replace capacitor ($15–$80 DIY, 30 min).

Is this capacitor compatible with Bryant or Payne too?

Many ICP parts are cross-compatible with Bryant and Payne since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across brand labels with different model numbers. To verify: check your Bryant or Payne equipment service manual for cross-compatible part numbers, or email info@nationalhvacparts.com with your model number.

Should I use OEM or aftermarket for my ICP capacitor?

OEM strongly recommended. OEM capacitors have ±6% MFD tolerance vs aftermarket ±10%. The looser tolerance causes motor winding stress, higher temps, and shorter compressor life. Price difference is only $10–$20 — OEM is the clear value choice.

How fast does National HVAC Parts ship?

Orders placed before 3:00 PM CST ship the same business day. Standard delivery is 2–5 business days anywhere in the continental United States. Express shipping available at checkout. We ship from Houston, TX to all 50 states. 30-day return policy on all parts.
