ICP Round Run Capacitor 2.0 MFD for YJ024GB1 — 440V with Clamp | Ships Today

Overview

This OEM ICP round run capacitor (part number 1095021) provides the steady phase shift a motor needs to run efficiently on your ICP/Tempstar/Heil YJ024GB1 system. Rated at 2.0 MFD and 440V, it ships with the mounting clamp so it can be secured cleanly inside the control box. A run capacitor stores and releases energy on each AC cycle to keep the motor windings energized at the correct phase angle; when it weakens, the motor draws excess current, runs hot, and can fail prematurely. A bulging top, leaked oil, or a reading that has drifted out of tolerance all point to a capacitor at the end of its life.

Specifications

Compatibility

Direct OEM replacement for the ICP/Tempstar/Heil YJ024GB1 and equivalent units in the same family that originally used part 1095021. A 440V-rated capacitor can safely replace a 370V unit of the same MFD. Verify the MFD rating stamped on your existing capacitor before ordering.

Installation Guide

1. Safety First — Disconnect power at the breaker and outdoor disconnect, then verify zero voltage with a multimeter. Discharge the old capacitor across its terminals with an insulated resistor before touching it.
2. Access — Remove the control panel to reach the capacitor.
3. Document — Photograph the wire colors on each terminal before disconnecting.
4. Remove — Loosen the mounting clamp and pull the leads off the spade terminals.
5. Install — Secure the new capacitor with the included clamp and reconnect each lead to the matching terminal per your photo.
6. Test — Restore power and confirm the motor starts smoothly and runs without hesitation.

Signs You Need a Replacement

• Bulging, domed, or leaking capacitor top
• Motor hums but won't start, or starts slowly
• Capacitance reads outside the rated 2.0 MFD (±6%)
• Frequent overload trips or a motor that runs hot

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.
