ICP Outdoor Thermostat for ZAXB020ECA1 — SPST 24V T6031 | Ships Today

Overview

This OEM outdoor thermostat (ICP part #1054570, Honeywell T6031H-style) is a temperature-sensing control used to stage supplemental or backup heat and to lock out heat-pump operation based on outdoor air temperature. It is a single-pole, single-throw (SPST) 24V control with an adjustable temperature setpoint. When the outdoor temperature crosses the setpoint, the contacts open or close to enable or disable a stage of heat, protecting compressor operation and improving efficiency. Common failure symptoms include backup heat that runs constantly, backup heat that never engages in cold weather, contacts that fail to make at the rated setpoint, or a sensing element that drifts out of calibration.

Specifications

Compatibility

Designed as a direct-fit replacement for ICP, Tempstar, Heil, and Comfortmaker equipment that uses the 1054570 outdoor thermostat, including model ZAXB020ECA1. Always verify the existing part number and setpoint range before installing.

Installation Guide

1. Safety First — Disconnect power at the unit and verify zero voltage with a multimeter.
2. Access — Remove the service/control-box panel to reach the thermostat.
3. Document — Photograph all wire connections before disconnecting.
4. Remove — Note the setpoint, disconnect the two 24V leads, and unscrew the old thermostat from its bracket.
5. Install — Mount the new thermostat, reconnect the leads per your photo, and set the temperature dial to the original setpoint.
6. Test — Restore power and confirm the stage of heat enables/disables at the correct outdoor temperature.

Signs You Need a Replacement

• Backup or supplemental heat runs even in mild weather
• No backup heat during cold outdoor temperatures
• Contacts do not switch at the dial setpoint
• Erratic staging or high electric bills from constant heat
