What igniter fits my ICP furnace?

The correct replacement for ICP model WPG4424090LKB1 — OEM Ignitor & Control Board | Ships Today is this exact part. It is the factory-specified replacement with exact OEM specifications. Using a part with different specifications can cause equipment damage or void your warranty. You can verify this by checking the data plate on your ICP equipment which lists the model number WPG4424090LKB1 — OEM Ignitor & Control Board | Ships Today.

My furnace will not ignite. What part is bad?

A furnace that will not ignite after the draft inducer runs typically has a failed igniter. The hot surface igniter should glow bright orange within 60 seconds. If it does not glow at all, it is cracked or burned out. If it glows weakly, it is degrading and should be replaced preventively. Average lifespan: 3 to 7 years.

ICP

ICP Hot Surface Igniter for WPG4424090LKB1 — OEM Ignitor & Control Board | Ships Today

Name: ICP Hot Surface Igniter for WPG4424090LKB1 — OEM Ignitor & Control Board | Ships Today
Brand: ICP
SKU: WPG4424090LKB1
Price: 58.44 USD
Availability: InStock

SKU: WPG4424090LKB1 Brand: ICP

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

Texas CMBL #19328542014

SAM.gov Registered

Govt POs Accepted

Overview

This genuine OEM hot surface igniter assembly covers the ignition components for the ICP / Tempstar / Heil WPG4424090LKB1 package gas/electric unit, including the ignitor (part number 1177663) and the igniter control board (part number 1186861). On a call for heat, the control board sequences the inducer and then sends voltage to the hot surface igniter, which glows red-hot to light the main burners. The igniter is the most failure-prone part in a gas heat cycle because the silicon-carbide or silicon-nitride element is brittle and degrades with every heat cycle. A cracked igniter or a board that no longer energizes it is the classic cause of a furnace that clicks, runs the inducer, but never lights.

Specifications

Spec	Value
Part Numbers	1186861 (Control Board Igniter), 1177663 (Ignitor)
Type	Hot Surface Igniter
Brand	ICP / Tempstar / Heil
Function	Burner Ignition
Fit	OEM Direct Replacement

Compatibility

Designed for the WPG4424090LKB1 package gas unit and related ICP, Tempstar, Heil, and Comfortmaker gas furnaces using this igniter and ignition control. Match your existing part numbers before ordering.

Installation Guide

Safety First — Disconnect power and shut off the gas supply, then verify zero voltage with a multimeter.
Access — Remove the burner access and control panels.
Document — Photograph the igniter mounting and all board wiring before disconnecting.
Remove — Unplug the igniter connector and remove its mounting screw; handle the fragile element only by its ceramic base, never the hot surface.
Install — Mount the new igniter so it aligns with the burner flame path, then reconnect the control board wiring per your photo.
Test — Restore gas and power, call for heat, and confirm the igniter glows and the burners light within the trial-for-ignition period.

Signs You Need a Replacement

Inducer runs but burners never ignite
Igniter does not glow or glows weakly
Visible crack or break in the igniter element
Furnace locks out after several failed ignition attempts

Shipping & Returns

Ships same day on orders placed before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.

Shipping Information

Orders placed before 3PM CST ship same business day
Standard delivery: 2-5 business days
Express shipping available at checkout
Free shipping on orders over $75
Tracking number emailed upon shipment

Return Policy

30-day returns on unused parts in original packaging
Electrical parts (capacitors, contactors, control boards) are final sale once installed
Email info@nationalhvacparts.com to initiate a return
Refunds processed within 5-7 business days

ICP Hot Surface Igniter for WPG4...

$58.44

Frequently Asked Questions

Does this Igniter fit my ICP WPG4424090LKB1 — OEM Ignitor & Control Board | Ships Today?

Yes. This is the factory-specified OEM igniter for the ICP WPG4424090LKB1 — OEM Ignitor & Control Board | Ships Today. It is a direct drop-in replacement that fits without modification. Always verify the model number on your equipment nameplate before ordering.

How do I replace the igniter on my ICP WPG4424090LKB1 — OEM Ignitor & Control Board | Ships Today?

Difficulty: Medium (20–30 min)
Step 1: Turn off power and gas. Step 2: Open furnace panel. Step 3: Locate igniter near burners. Step 4: Disconnect two-wire plug. Step 5: Remove mounting screw. Step 6: Install new igniter — do NOT touch element with fingers. Step 7: Reconnect, close panel, restore power/gas.

My furnace won’t ignite. What part is bad?

Furnace won’t ignite after the draft inducer runs = failed igniter. The hot surface igniter should glow bright orange within 60 seconds. No glow = cracked/burned out. Weak glow = degrading. Average lifespan: 3–7 years. Replacement: $15–$40 DIY.

Is this igniter compatible with Bryant or Payne too?

Many ICP parts are cross-compatible with Bryant and Payne since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across brand labels with different model numbers. To verify: check your Bryant or Payne equipment service manual for cross-compatible part numbers, or email info@nationalhvacparts.com with your model number.

Should I use OEM or aftermarket for my ICP igniter?

OEM recommended for reliability and warranty compatibility. OEM parts match exact factory specifications for proper fit, performance, and safety. While aftermarket alternatives cost less upfront, the risk of improper fit and reduced lifespan usually makes OEM the better value long-term.

How fast does National HVAC Parts ship?

Orders placed before 3:00 PM CST ship the same business day. Standard delivery is 2–5 business days anywhere in the continental United States. Express shipping available at checkout. We ship from Houston, TX to all 50 states. 30-day return policy on all parts.
