Overview

This OEM hot surface igniter kit fits the ICP / Tempstar / Heil WFAR120D060A1 furnace and includes the igniter (part number 1176919) and its mounting bracket (part number 1184324). On every call for heat, the control board energizes the igniter; it glows orange-hot and lights the burners. Hot surface igniters are the most common furnace failure point because the brittle silicon-carbide or silicon-nitride element degrades with each heating cycle and eventually cracks. A failed igniter leaves you with a furnace that runs the inducer and blower but never produces flame.

Specifications

Compatibility

Designed for the ICP WFAR120D060A1 and compatible Tempstar/Heil/Comfortmaker furnaces using this hot surface igniter and bracket assembly. Match the bracket geometry and connector to your existing unit before installing.

Installation Guide

1. Safety First — Disconnect power at the furnace switch and breaker, then verify zero voltage with a multimeter.
2. Access — Remove the burner compartment service panel.
3. Document — Photograph the igniter position, bracket alignment, and wire routing before disconnecting.
4. Remove — Unplug the igniter connector, remove the bracket screws, and lift out the old igniter. Do not touch the new element with bare fingers — skin oils cause hot spots.
5. Install — Mount the new igniter on the bracket, position it in the burner flame path, and reconnect the plug per your photo.
6. Test — Restore power, call for heat, and watch the igniter glow and light the burners.

Signs You Need a Replacement

• Furnace cycles the inducer and blower but never lights
• Visible crack or break in the igniter element
• Igniter no longer glows on a heat call
• Open-circuit reading when measuring igniter resistance
