What igniter fits my ICP furnace?

The correct replacement for ICP model WPG4364060RKB1 — Ships Today is this exact part. It is the factory-specified replacement with exact OEM specifications. Using a part with different specifications can cause equipment damage or void your warranty. You can verify this by checking the data plate on your ICP equipment which lists the model number WPG4364060RKB1 — Ships Today.

My furnace will not ignite. What part is bad?

A furnace that will not ignite after the draft inducer runs typically has a failed igniter. The hot surface igniter should glow bright orange within 60 seconds. If it does not glow at all, it is cracked or burned out. If it glows weakly, it is degrading and should be replaced preventively. Average lifespan: 3 to 7 years.

ICP

ICP Hot Surface Igniter & Control Board for WPG4364060RKB1 — Ships Today

Name: ICP Hot Surface Igniter & Control Board for WPG4364060RKB1 — Ships Today
Brand: ICP
SKU: WPG4364060RKB1
Price: 45.44 USD
Availability: InStock

SKU: WPG4364060RKB1 Brand: ICP

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

Texas CMBL #19328542014

SAM.gov Registered

Govt POs Accepted

Overview

This OEM hot surface igniter assembly (igniter #1177663 with control board igniter #1186861) is built for the gas-heat section of the ICP / Tempstar / Heil WPG4364060RKB1 packaged gas-electric unit. The hot surface igniter glows red-hot on a call for heat to ignite the burner gas, while the igniter control circuit sequences the timing safely. Igniter elements are brittle and degrade with every heating cycle — they crack, develop hairline fractures, or lose the ability to reach ignition temperature, which leaves you with no heat, delayed ignition, or a furnace that locks out after several failed trials. Replacing the igniter with this OEM-spec part restores fast, reliable burner ignition and clears the most common cause of no-heat lockouts.

Specifications

Spec	Value
Igniter Part Number	1177663
Control Board Igniter	1186861
Type	Hot Surface Igniter
Brand	ICP (Tempstar / Heil)
Fits Model	WPG4364060RKB1
Fitment	OEM

Compatibility

Designed for the gas-fired heating section of the ICP / Tempstar / Heil / Comfortmaker WPG4364060RKB1 packaged gas-electric unit. Match the connector style and mounting bracket to your original before installing.

Installation Guide

Safety First — Shut off the gas and disconnect power, then verify zero voltage with a multimeter.
Access — Remove the burner compartment service panel.
Document — Photograph the igniter bracket position and wiring harness routing.
Remove — Unplug the igniter connector and unscrew the mounting bracket. Handle the new igniter only by its ceramic base — never touch the silicon-nitride element.
Install — Mount the new igniter so the element seats in the burner flame path, then reconnect the harness.
Test — Restore gas and power, call for heat, and confirm the igniter glows and the burners light within the normal trial period.

Signs You Need a Replacement

No heat with a furnace that locks out after several ignition trials
Igniter shows visible cracks or no longer glows
Delayed ignition or a small "poof" at burner light-off
Out-of-spec resistance reading across the igniter element

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.

Shipping Information

Orders placed before 3PM CST ship same business day
Standard delivery: 2-5 business days
Express shipping available at checkout
Free shipping on orders over $75
Tracking number emailed upon shipment

Return Policy

30-day returns on unused parts in original packaging
Electrical parts (capacitors, contactors, control boards) are final sale once installed
Email info@nationalhvacparts.com to initiate a return
Refunds processed within 5-7 business days

ICP Hot Surface Igniter & Contro...

$45.44

Frequently Asked Questions

Does this Igniter fit my ICP WPG4364060RKB1 — Ships Today?

Yes. This is the factory-specified OEM igniter for the ICP WPG4364060RKB1 — Ships Today. It is a direct drop-in replacement that fits without modification. Always verify the model number on your equipment nameplate before ordering.

How do I replace the igniter on my ICP WPG4364060RKB1 — Ships Today?

Difficulty: Medium (20–30 min)
Step 1: Turn off power and gas. Step 2: Open furnace panel. Step 3: Locate igniter near burners. Step 4: Disconnect two-wire plug. Step 5: Remove mounting screw. Step 6: Install new igniter — do NOT touch element with fingers. Step 7: Reconnect, close panel, restore power/gas.

My furnace won’t ignite. What part is bad?

Furnace won’t ignite after the draft inducer runs = failed igniter. The hot surface igniter should glow bright orange within 60 seconds. No glow = cracked/burned out. Weak glow = degrading. Average lifespan: 3–7 years. Replacement: $15–$40 DIY.

Is this igniter compatible with Bryant or Payne too?

Many ICP parts are cross-compatible with Bryant and Payne since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across brand labels with different model numbers. To verify: check your Bryant or Payne equipment service manual for cross-compatible part numbers, or email info@nationalhvacparts.com with your model number.

Should I use OEM or aftermarket for my ICP igniter?

OEM recommended for reliability and warranty compatibility. OEM parts match exact factory specifications for proper fit, performance, and safety. While aftermarket alternatives cost less upfront, the risk of improper fit and reduced lifespan usually makes OEM the better value long-term.
