ICP ECM X-13 Motor Control for WPH3304000RKC1 — 1/2 HP | Ships Today

Overview

This is the genuine OEM ECM X-13 motor control module (part 1185843), a 1/2 HP electronically commutated blower motor control for the ICP / Tempstar / Heil WPH3304000RKC1 packaged heat pump. The X-13 is a constant-torque ECM that delivers efficient, quiet airflow and holds its programmed torque tap across varying static pressure. When the control fails you'll see a blower that won't start, runs at the wrong speed, surges, or hums without turning. Replacing the module restores correct, energy-efficient air delivery.

Specifications

Compatibility

Designed for the ICP WPH3304000RKC1 packaged heat pump and Tempstar, Heil, and Comfortmaker equivalents using a 1/2 HP ECM X-13 blower motor. Confirm horsepower and the X-13 control type before ordering.

Installation Guide

1. Safety First — Disconnect power at the breaker and verify zero voltage; allow the ECM to discharge before handling.
2. Access — Remove the blower-compartment service panel and pull the blower assembly if needed.
3. Document — Photo the line/neutral and the low-voltage tap connections on the control.
4. Remove — Unplug the harnesses and separate the control module from the motor end shield.
5. Install — Mate the new control to the motor, reconnect the power and tap harnesses per your photo.
6. Test — Restore power, run the blower, and confirm correct speed and smooth, quiet operation.

Signs You Need a Replacement

• Blower won't start or only hums without spinning.
• Motor runs at the wrong speed or surges up and down.
• Intermittent operation that stops and restarts on its own.
• Burnt-electronics smell or visible scorching on the module.

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. Backed by the National HVAC Parts fitment guarantee.
