ICP ECM X-13 Blower Motor Control for WJA336000KTP0B1 — 1/2 HP | Ships Today

Overview

This OEM ECM X-13 motor control module (part 1185844) is the electronic control for the 1/2 HP variable-speed blower motor in the ICP / Tempstar / Heil WJA336000KTP0B1. The X-13 is a constant-torque ECM design — the control module receives 24V tap selections from the furnace board and drives the motor at the programmed torque for each heating, cooling, and fan stage. It delivers quieter operation and better efficiency than a standard PSC motor. When the control module fails, the blower may not start, run only at one speed, ramp erratically, or trip on internal faults, leaving the system with poor airflow or no airflow at all.

Specifications

Compatibility

Designed for the ICP WJA336000KTP0B1 and compatible Tempstar, Heil, and Comfortmaker air handlers and furnaces using the 1185844 X-13 motor control. Match the part number and horsepower to your existing control module before ordering.

Installation Guide

1. Safety First — Disconnect power at the breaker and verify zero voltage with a multimeter; allow the ECM to discharge for several minutes.
2. Access — Remove the blower compartment door to reach the motor assembly.
3. Document — Photograph the 24V control plug taps and the 5-pin power connector before unplugging.
4. Remove — Separate the control module from the motor end shield by removing the retaining bolts and the connectors.
5. Install — Mate the new control module to the motor, reconnect the power and control plugs per your photo.
6. Test — Restore power and verify the blower ramps and runs correctly on heat, cool, and fan-only calls.

Signs You Need a Replacement

• Blower will not start on any call
• Motor runs at only one speed or ramps erratically
• Weak or no airflow from the registers
• Buzzing, stalling, or repeated shutdowns at the motor
