What are the specs for this Thermostat?

The correct replacement for ICP model YD060GA — 75/55°F | Ships Today is this exact part. It is the factory-specified replacement with exact OEM specifications. Using a part with different specifications can cause equipment damage or void your warranty. You can verify this by checking the data plate on your ICP equipment which lists the model number YD060GA — 75/55°F | Ships Today.

What symptoms indicate I need a new thermostat?

Common symptoms that indicate you need a new thermostat include unusual noises, intermittent operation, complete failure to operate, or visible damage. For specific diagnostic guidance, visit nationalhvacparts.com/pages/hvac-diagnostic.

ICP

ICP Crankcase Heater Thermostat for YD060GA — 75/55°F | Ships Today

Name: ICP Crankcase Heater Thermostat for YD060GA — 75/55°F | Ships Today
Brand: ICP
SKU: 14124800
Price: 29.90 USD
Availability: InStock

SKU: 14124800 Brand: ICP

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

Texas CMBL #19328542014

SAM.gov Registered

Govt POs Accepted

Overview

This OEM crankcase heater thermostat (part 14124800) is a snap-disc temperature switch that controls the compressor crankcase heater on the ICP YD060GA. Rated to close around 55°F and open around 75°F, it energizes the crankcase heater in cold ambient conditions to keep refrigerant from migrating and condensing in the compressor oil. This prevents liquid slugging and oil dilution on start-up — a leading cause of compressor failure in cool weather. A faulty thermostat that stays open leaves the heater off when it's needed (risking compressor damage), while one stuck closed wastes energy by running the heater continuously. Replacing it restores correct, temperature-controlled crankcase heating.

Specifications

Spec	Value
Part Number	14124800
Type	Crankcase Heater Snap-Disc Thermostat
Brand	ICP (Tempstar / Heil / Comfortmaker)
Set Point	Open ~75°F / Close ~55°F
Application	Compressor crankcase heater control

Compatibility

OEM replacement for ICP model YD060GA and matching Tempstar, Heil, and Comfortmaker condensing units that use the 75/55°F crankcase heater thermostat, part 14124800. Confirm the part number and temperature rating on your existing switch before ordering.

Installation Guide

Safety First — Disconnect power at the breaker and outdoor disconnect, then verify zero voltage with a multimeter.
Access — Remove the outdoor unit service panel to reach the compressor and crankcase heater wiring.
Document — Photograph the thermostat leads and its mounting location on the compressor body.
Remove — Disconnect the leads, release the mounting clip or bracket, and remove the old snap-disc from the compressor shell.
Install — Mount the new thermostat in firm contact with the compressor shell and reconnect the leads per your photo.
Test — Restore power and verify the heater energizes when the shell is cold and de-energizes as it warms.

Signs You Need a Replacement

Crankcase heater never warms in cold weather
Compressor noisy or slugging on cold start-up
Heater runs continuously even in warm ambient
Thermostat reads open/closed incorrectly for the temperature

Shipping & Returns

Ships same day before 3 PM CST. 30-day returns. National HVAC Parts fitment guarantee.

Shipping Information

Orders placed before 3PM CST ship same business day
Standard delivery: 2-5 business days
Express shipping available at checkout
Free shipping on orders over $75
Tracking number emailed upon shipment

Return Policy

30-day returns on unused parts in original packaging
Electrical parts (capacitors, contactors, control boards) are final sale once installed
Email info@nationalhvacparts.com to initiate a return
Refunds processed within 5-7 business days

ICP Crankcase Heater Thermostat ...

$29.90

Frequently Asked Questions

Does this Thermostat fit my ICP YD060GA — 75/55°F | Ships Today?

Yes. This is the factory-specified OEM thermostat for the ICP YD060GA — 75/55°F | Ships Today. It is a direct drop-in replacement that fits without modification. Always verify the model number on your equipment nameplate before ordering.

How do I replace the thermostat on my ICP YD060GA — 75/55°F | Ships Today?

Refer to your equipment service manual for model-specific steps. General approach: turn off power, photograph connections, remove old part, install new part, restore power and test. For gas components, hire a licensed technician. Email info@nationalhvacparts.com for guidance.

What symptoms mean I need a new thermostat?

Common symptoms: unusual noises, intermittent operation, complete failure, or visible damage. Visit our diagnostic hub for symptom-based troubleshooting.

Is this thermostat compatible with Bryant or Payne too?

Many ICP parts are cross-compatible with Bryant and Payne since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across brand labels with different model numbers. To verify: check your Bryant or Payne equipment service manual for cross-compatible part numbers, or email info@nationalhvacparts.com with your model number.

Should I use OEM or aftermarket for my ICP thermostat?

OEM recommended for reliability and warranty compatibility. OEM parts match exact factory specifications for proper fit, performance, and safety. While aftermarket alternatives cost less upfront, the risk of improper fit and reduced lifespan usually makes OEM the better value long-term.

How fast does National HVAC Parts ship?

Orders placed before 3:00 PM CST ship the same business day. Standard delivery is 2–5 business days anywhere in the continental United States. Express shipping available at checkout. We ship from Houston, TX to all 50 states. 30-day return policy on all parts.
