Overview
This is a genuine OEM crankcase heater thermostat (part #14124800, "TSTAT CC HTR 75/55") for the ICP / Tempstar / Heil YD030GA condensing unit. It is a temperature-sensing bimetal snap-disc switch that energizes the compressor crankcase heater whenever the outdoor ambient drops, protecting the compressor from refrigerant migration and liquid slugging on cold-weather start-up. The "75/55" rating means the contacts make and break across the 55°F–75°F band so the heater only runs when it is actually needed. A failed thermostat either leaves the crankcase heater on continuously (wasting energy and overheating oil) or never energizes it (risking compressor flooding, hard starts, and bearing wear). Replacing this inexpensive switch is far cheaper than a compressor.
Specifications
| Spec | Value |
|---|---|
| Part Number | 14124800 |
| Type | Bimetal Snap-Disc Crankcase Heater Thermostat |
| Brand | ICP / Tempstar / Heil / Comfortmaker |
| Setpoint | Close 75°F / Open 55°F (approx.) |
| Control Voltage | 24V |
| Mounting | Clip/strap to compressor crankcase |
Compatibility
Directly fits the ICP/Tempstar/Heil YD030GA heat pump/condenser and other ICP-family units that originally shipped with crankcase heater thermostat 14124800. Always verify the printed part number on the old switch before ordering.
Installation Guide
- Safety First — Disconnect power at the outdoor disconnect and verify zero voltage with a multimeter.
- Access — Remove the condenser service/corner panel to reach the compressor.
- Document — Photograph the existing thermostat location and wire connections before disconnecting.
- Remove — Detach the strap/clip, unplug the leads, and remove the old snap-disc from the crankcase.
- Install — Mount the new thermostat in firm contact with the crankcase, reconnect the leads per your photo.
- Test — Restore power and confirm the crankcase heater energizes in cold ambient and de-energizes as the disc warms.
Signs You Need a Replacement
- Crankcase heater runs constantly regardless of outdoor temperature
- Compressor floods, hard-starts, or trips on cold mornings
- No continuity across the disc within its rated temperature band
- Visible corrosion, cracked disc, or burned terminals
