ICP Crankcase Heater Thermostat for YD024GA — 75/55°F Snap Disc 24V | Ships Today
OEM Guaranteed
Same-Day Ship
30-Day Returns
Secure Checkout
Overview
This is a genuine OEM crankcase heater thermostat (part #14124800, "TSTAT CC HTR 75/55") for the ICP / Tempstar / Heil YD024GA condensing unit. It is a temperature-sensing bimetal snap-disc switch that energizes the compressor crankcase heater in cold weather to keep refrigerant from migrating into and condensing in the compressor oil. The "75/55" rating means the contacts cycle across the 55°F–75°F band so the heater operates only when needed, preventing both energy waste and cold-start liquid slugging. When this thermostat fails, the crankcase heater either stays on continuously (overheating the oil and wasting power) or never comes on (allowing refrigerant flooding, hard starts, and premature compressor wear). It is an inexpensive part that protects an expensive compressor.
Specifications
| Spec | Value |
|---|---|
| Part Number | 14124800 |
| Type | Bimetal Snap-Disc Crankcase Heater Thermostat |
| Brand | ICP / Tempstar / Heil / Comfortmaker |
| Setpoint | Close 75°F / Open 55°F (approx.) |
| Control Voltage | 24V |
| Mounting | Clip/strap to compressor crankcase |
Compatibility
Directly fits the ICP/Tempstar/Heil YD024GA condenser/heat pump and other ICP-family units originally supplied with crankcase heater thermostat 14124800. Always verify the printed part number on the old switch before ordering.
Installation Guide
- Safety First — Disconnect power at the outdoor disconnect and verify zero voltage with a multimeter.
- Access — Remove the condenser service/corner panel to reach the compressor.
- Document — Photograph the existing thermostat location and wire connections before disconnecting.
- Remove — Detach the strap/clip, unplug the leads, and remove the old snap-disc from the crankcase.
- Install — Mount the new thermostat in firm contact with the crankcase and reconnect the leads per your photo.
- Test — Restore power and confirm the crankcase heater energizes in cold ambient and de-energizes as the disc warms.
Signs You Need a Replacement
- Crankcase heater runs constantly regardless of outdoor temperature
- Compressor floods, hard-starts, or trips on cold mornings
- No continuity across the disc within its rated temperature band
- Visible corrosion, cracked disc, or burned terminals
