ICP Blower Motor for WPG4304040RKA1 — 1/2 HP X-13 ECM | Ships Today
OEM Guaranteed
Same-Day Ship
30-Day Returns
Secure Checkout
Overview
This is the genuine OEM 1/2 HP X-13 blower motor (part 1186863) for the ICP / Tempstar / Heil WPG4304040RKA1 package unit. The X-13 is a constant-torque ECM (electronically commutated motor) that drives the indoor blower wheel, moving conditioned air through the duct system on both heating and cooling cycles. Compared to old PSC motors, the X-13 runs more efficiently, holds airflow steady against duct static, and stages off the control board's selected taps. A failing blower motor leads to weak airflow, overheating limit trips in heat mode, frozen coils in cool mode, or a complete no-airflow condition. This OEM motor restores rated CFM and quiet operation.
Specifications
| Spec | Value |
|---|---|
| Part Number | 1186863 |
| Type | Blower Motor, X-13 Constant-Torque ECM |
| Brand | ICP / Tempstar / Heil |
| Horsepower | 1/2 HP |
| Application | Indoor furnace/air-handler blower |
Compatibility
Built as the factory blower replacement for the ICP WPG4304040RKA1 packaged system and used across comparable ICP, Tempstar, Heil, and Comfortmaker units that specify a 1/2 HP X-13 motor. Confirm shaft diameter, rotation, mounting, and the motor's program/tap configuration match your original before installing.
Installation Guide
- Safety First — Disconnect power at the breaker and unit disconnect, then verify zero voltage with a multimeter.
- Access — Remove the blower-compartment panel and slide out the blower assembly.
- Document — Photograph the motor wiring, tap connections, and blower-wheel position on the shaft.
- Remove — Loosen the wheel set screw, pull the wheel, then unbolt the motor from the housing.
- Install — Mount the new motor, set the blower wheel to the same depth, and reconnect the harness per your photo.
- Test — Restore power, run heat and cool cycles, and confirm strong, steady airflow with no vibration.
Signs You Need a Replacement
- Weak or no airflow from the supply registers.
- Furnace trips on high-limit from low airflow in heat mode.
- Evaporator coil freezing up during cooling.
- Loud humming, grinding, or a motor that runs hot and cycles off.
