OEM Carrier Condenser Fan Motor 1HP 208-230/460V 3-Phase for Model 09DK074900

This OEM condenser fan motor is the factory-specified replacement for the Carrier 09DK074900 commercial cooling system. The condenser fan motor drives the outdoor fan blade to pull ambient air across the condenser coil, rejecting heat and maintaining refrigerant pressure within design parameters. When this motor fails, symptoms include the condenser fan not spinning, the unit tripping on high-pressure lockout, compressor overheating, or complete loss of cooling capacity. A seized or thermally-open motor must be replaced promptly to prevent compressor damage.

• Specs: 1 HP | 208-230/460V | 3-Phase | 1140 RPM | Frame 56Y | CCW Rotation | 6.5/3.3A Full Load | Insulation Class F | OEM Part Numbers: HD52AK001, HD52AK652, HD52AK653, HD52AK654, HD52AK002
• OEM vs Generic: This is a genuine Carrier factory-authorized part engineered to exact tolerances for the 09DK074900 platform. Generic 3-phase motors frequently deviate in frame dimensions, shaft length, and winding impedance — mismatches that cause vibration, premature bearing failure, and VFD incompatibility on commercial equipment.
• Install difficulty: 4/5 — Requires licensed commercial HVAC technician. Lock out/tag out (LOTO) required before servicing. Tools needed: multimeter with phase-rotation tester, conduit wrench, shaft puller, torque wrench. Verify phase rotation matches original before energizing. Always inspect fan blade for balance and damage before reinstalling.
• Warranty: 1-year OEM factory warranty. Ships same business day from our warehouse in original factory packaging.

Compatibility: Designed for the Carrier 09DK074900 commercial condensing unit. Cross-reference OEM part numbers HD52AK001, HD52AK652, HD52AK653, HD52AK654, and HD52AK002 — all are factory-authorized variants for this motor position. Note: HD52AK001 has been superseded by HD52AZ001; confirm your unit's motor data plate specs (voltage, HP, RPM, frame) before ordering. Our technical team is available to verify fitment prior to purchase.
