OEM Carrier Condenser Fan Motor 1HP 1140RPM 3PH — 09DK054600
Carrier

OEM Carrier Condenser Fan Motor 1HP 1140RPM 3PH — 09DK054600

SKU: CARRIE-09DK054600-FAN_MOTOR-HD52AK001 Brand: Carrier

Order before 3PM CST — ships same day.
Standard delivery 2-5 business days. Express options at checkout.

OEM Guaranteed

Same-Day Ship

30-Day Returns

Secure Checkout

OEM Carrier Condenser Fan Motor 1HP 208-230/460V 3-Phase for Model 09DK054600

This OEM condenser fan motor is the factory-specified replacement for the Carrier 09DK054600 commercial cooling unit. The condenser fan motor drives the fan blade that forces ambient air across the condenser coil, rejecting heat from the refrigerant circuit. When this motor fails, the condenser loses its ability to reject heat — leading to high-pressure lockout, system overheating, compressor damage, or complete cooling failure. Common symptoms include a humming condenser with no fan spin, intermittent fan operation, or the unit tripping on high-pressure safety. OEM part numbers covered by this listing: HD52AK001, HD52AK653, HD52AK654, HD52AK002.

  • Specs: 1 HP | 208-230/460V | 3-Phase | 1140 RPM | Frame 56Y | CCW Rotation | 6.5/3.3A Full Load | Class F Insulation | Factory-matched dimensions for drop-in fit
  • OEM vs Generic: This OEM motor meets Carrier's exact torque curve, insulation class, and frame tolerances. Off-brand replacements often run at ±10% RPM variance, reducing condenser efficiency and stressing the compressor — especially critical on commercial 3-phase systems like the 09DK054600.
  • Install difficulty: 3/5 — Requires lockout/tagout of 3-phase power before any work begins. Tools needed: multimeter (phase verification), torque wrench, 1/2" socket set, shaft puller for fan blade transfer. Always verify rotation direction (CCW) and recheck amp draw after startup. Consult a licensed HVAC technician if unfamiliar with 3-phase motor wiring.
  • Warranty: 1-year OEM factory warranty. Ships same business day from our warehouse when ordered before cutoff.

Compatibility: Engineered for Carrier model 09DK054600 commercial condensing units. Cross-references OEM part numbers HD52AK001, HD52AK653, HD52AK654, and HD52AK002. Verify voltage supply (208-230V or 460V wiring configuration) and frame size on your unit's data plate before ordering. Need fitment confirmation? Our HVAC parts specialists verify compatibility before you buy — contact us today and get it shipped same day.

Shipping Information

  • Orders placed before 3PM CST ship same business day
  • Standard delivery: 2-5 business days
  • Express shipping available at checkout
  • Free shipping on orders over $75
  • Tracking number emailed upon shipment

Return Policy

  • 30-day returns on unused parts in original packaging
  • Electrical parts (capacitors, contactors, control boards) are final sale once installed
  • Email support@nationalhvacparts.com to initiate a return
  • Refunds processed within 5-7 business days

Frequently Asked Questions

Does this Fan Motor fit my Carrier OEM Carrier Condenser Fan Motor 1HP 1140RPM 3PH — 09DK054600?
Yes. This is the factory-specified OEM fan motor for the Carrier OEM Carrier Condenser Fan Motor 1HP 1140RPM 3PH — 09DK054600. It is a direct drop-in replacement that fits without modification. Always verify the model number on your equipment nameplate before ordering.
How do I replace the fan motor on my Carrier OEM Carrier Condenser Fan Motor 1HP 1140RPM 3PH — 09DK054600?
Difficulty: Medium-Hard (1–2 hrs)
Step 1: Turn off breaker. Step 2: Note motor specs: HP, RPM, voltage, rotation direction. Step 3: Remove old motor from mounting. Step 4: Transfer fan blade to new motor. Step 5: Mount new motor, reconnect wiring. Step 6: Restore power, verify rotation direction.
My AC fan isn’t spinning. What part do I need?
Fan not spinning, spinning slowly, or making grinding/squealing noises = motor failure. Grinding = bearings failed. Squealing = bearings dry. No spin + hum = check the motor capacitor first before replacing the entire motor.
Is this fan motor compatible with Bryant or Payne too?
Many Carrier parts are cross-compatible with Bryant and Payne since all three brands are manufactured by Carrier Global Corporation. The same physical part is often used across brand labels with different model numbers. To verify: check your Bryant or Payne equipment service manual for cross-compatible part numbers, or email info@nationalhvacparts.com with your model number.
Should I use OEM or aftermarket for my Carrier fan motor?
OEM recommended for reliability and warranty compatibility. OEM parts match exact factory specifications for proper fit, performance, and safety. While aftermarket alternatives cost less upfront, the risk of improper fit and reduced lifespan usually makes OEM the better value long-term.
